Harloff Triple Column Mobile Cabinet with Key Locking Tambour Door, MSPM83-L0TK-SPLITB
- Authorized Distributor
- Direct manufacturer partnership
- Secure B2B Checkout
- Encrypted facility purchasing
- Fast Shipping
- Ships in 2-4 business days
- Warranty
- Manufacturer-backed warranty
The Harloff MSPM83-L0TK-SPLITB is the mirrored counterpart to Harloff's SPLITA triple-column mobile cabinet: a single full-height H+H column on the left, and a split right-hand column with the double-width open storage section on top and the modular tray/basket section below. Choosing SPLITB over SPLITA is purely about which zone a department wants at reach height versus down low, the cabinet is otherwise built to the same MedStor Max standard, secured by a roll-up tambour door with a standard key lock. This configuration is the current-catalog build of Harloff's legacy part number MS8161L-SPLITB (itself a successor to MS8160L-SPLITB).
All three columns share a true 24" interior depth, deep enough for standard supply boxes stored two feet deep. The single left column carries H+H panels rated for 49 insertion points; the split right column offers 19 insertion points on each side of the split for H+H trays, plus 28 insertion points total across the double-wide section for bulkier accessories, giving staff three distinct, independently organizable storage zones without three separate cabinet footprints.
The roll-up tambour door opens with one upward motion and locks the entire cabinet front with a single key turn, faster in a busy hallway than managing separate hinged doors per column. The cabinet rolls on 5" quiet rolling casters (one steering, one braking), is delivered fully assembled, and stacks flush against walls and neighboring cabinets since Harloff's MedStor Max line skips bulky exterior handles. As with every MedStor Max cabinet, trays, baskets, shelves, and catheter slides are sold separately so each department can populate the insertion points with exactly the storage accessories its supply mix requires.
At roughly 80"H x 64"W x 30"D and 445 lbs, this is built for central supply, surgical services, and sterile processing areas consolidating multiple storage categories into one mobile cabinet. If your floor plan or workflow favors bulk open storage up top and modular trays within easier reach below, SPLITB is the layout to choose over SPLITA. Backed by Harloff's 12-year limited manufacturer's warranty. Buying for a facility? Contact Mediplies for bulk and case pricing, with fast, insured nationwide shipping.
Triple-column mobile cabinet: single H+H column (left) + split column (right) for double-wide open storage above, trays below
Mirrored layout of the SPLITA configuration — choose based on which zone should sit at reach height
Roll-up tambour door with standard key lock secures the entire cabinet front in one motion
H+H panels give 49 insertion points in the single column; split column offers 19 points per side (28 total for double-wide accessories)
Current-catalog build of legacy part number MS8161L-SPLITB (successor to MS8160L-SPLITB)
True 24" interior depth throughout — stores standard supply boxes two feet deep
5" quiet rolling casters (1 steering, 1 braking) for controlled mobility
Delivered fully assembled; engineered and manufactured in the USA
| Brand / Manufacturer | Harloff |
|---|---|
| SKU | MSPM83-L0TK-SPLITB |
| Category | Medical Carts |
| Availability | In stock — ships from the USA |
Specifications sourced from the manufacturer. Need a detail that isn't listed? Ask our team →
