Wolf X-Ray Trimline III 3-Bulb X-Ray Illuminator, Surface Mount (23466)

Wolf X-Ray's Trimline III Illuminator, Model 23466is the full 6-over-6 bank configuration of the Trimline III line, two rows of six 14"x17" viewing panels (12 panels total) built into a single surface-mounted illuminator, sized for reading rooms that need to keep a full study, or several studies side by side, lit and visible at once.

Each of the 12 panels carries three 15-watt daylight-balanced lamps (36 lamps total, all included), delivering a bright, even, non-glare field across the entire 84" wide x 34" tall viewing surface. The complete unit mounts to the wall at 44"H x 84"W x 3-1/4"D and weighs 205 lbs; an optional recessing kit (Wolf stock #21766, 6 lbs) is available for facilities that want a flush, built-in finish instead of a surface-mounted profile.

Every panel switches itself on automatically the instant film is loaded and off again when it's pulled, so with 12 panels in play, only the ones actually in use are ever lit. That film-activated switching eliminates light leakage and glare from idle panels, keeps heat output down across a bank this size, and means staff never have to remember to flip a dozen individual switches at the end of a shift. The cabinet is a baked-on white polyester powder-coat finish, film is held by scratch-free roller-grip retainers, and the unit is UL, CSA, and ETL listed.

This is the configuration to specify for a busy multi-view radiology reading wall, an orthopedic group that reviews several series at once, or any department consolidating multiple smaller illuminators into one bank. Mediplies ships the 23466 insured, nationwide, contact us for facility and volume pricing.
